Multi-product + Advanced Technology + System Solution
M&R sets high quality products and advanced technology in one, in addition to the lifting industry experts and experience A wealth of engineers; It also offers a wide range of products and safe and reliable system solutions.And to best serve our customers.


多元產品+先進技術+系統方案
邁德銳集高質產品與先進技術，除了擁有起重行業專家和經驗豐富的工程師； 還提供豐富多元的產品和安全可靠的系統解決方案，并以最佳方式服務于我們的客戶。
MRG SERIES EUROPEAN ELECTRIC WIRE ROPE HOIST
MRG歐式電動鋼絲繩葫蘆

PRODUCT ADVANTAGES:
產品優勢
A厚積薄發，創新之作
Accumulation and Innovation
A結構緊湊，節能環保
Compact structure, excellent performance
A高效傳動，效率之源
Efficient Transmission and power source
A卓越性能，安全可靠
Excellent performance, safe and reliable

Standard Configuration Of BMG Series Wire Rope Electric Hoists 標準供貨范圍
?lt~32t    ； 32t~100t 標配升電機
Double speed lifting motor with 1 ton-32ton standard variable
?朝電制動器，
Frequency lifting motor with 32ton to 10Oton standard Lifting electromagnetic disc brake and maintenance-free design
?380V/3Ph/50Hz 供電電壓
380V/3P/50HZ supply voltage
?控制電壓48V
Control voltage 48V

Lifting limit switch
?運行電機，速度5~20m/min
Variable frequency motor of trolley with the speed of 5/20m/min
?電機防護等級IP55 ,絕緣等級F
Protection grade of electric motor is Grade IP55, and insulation grade is F
?吊鉤組,帶扣
Lifting hook group with safety clasp
?起重機限制器
Load lifting limiter
?使用環境溫度:-20°C~+40°C
Environment temperature :-20C°-+40C°

Compact structure, light self-weight, small wheel-pressure and high comprehensive cost performance
結構緊湊，自輪壓小，性價比高
邁德銳領先的技術部件性能保證了產品最優的極限尺寸和設備高度,在保證高效 性能前提下結構緊湊,同樣的廠房和工作區域內，邁德銳歐式電動鋼絲繩葫蘆能 夠覆蓋更大的作業范圍，增大廠房內部面積的利用率，減小盲區。如果在廠房設計 階段就應邁德銳的產品系列參數進行設計，可以大大降低起重設備對廠房高度 和的要求。
Leading technology and component performance ensure the optimal extreme dimension of the products and the height of equipment and the compact structure under the premise of ensuring the high efficiency. Within the same plant and working area, MRG series European Electric Wire Rope Hoist can cover larger working range, which increases the utilization of the internal area of the plant and decreases the dead zone,if the plant is designed in accordance with he parameters of series of products of M&R during the design stage, Requirements for the lifting equipment can be greatly reduced for the height and bearing capacity of the plant, which reduces above 10% of plant investment for the customers and improves the efficiency of investment.
Save operating costs and green energy saving
節約運行，綠色節能
邁德銳配置MRG系列歐式電動鋼絲繩葫蘆的歐式起重機可以明顯降低主梁及整機自重，相對同樣國產的廠區，平均每年省30%.同時，邁德銳電動葫蘆運行噪音優于國家標準，營造出更加安靜的工作空間。
European type cranes equipped with MRG series European Electric Wire Rope Hoists can significantly reduce self-weight of the girder and the complete machine, and decrease the total power of running, as well as can save over 30% of power per year on average compared with the plants hose use the domestic traditional cranes, Meanwhile, the running noise is superior to the national standard of MRG series European

Electric Wire Rope Hoist .which created a move quiet work space.
Selection of high quality of components with safety and reliability and durable in use
優質部件，安全可靠，堅固耐用
邁德銳高品質部件是產品卓越品質基礎，從起升電機到減速器,從卷筒到鋼絲 繩,從安全可靠的電氣元件到精益求精的結構件，邁德銳認真對待每一個部件， 因?yàn)橹挥懈鱾€(gè)部件擁有良好的性能和質量才能確保整機的性能和品質。結構緊湊、 性能卓越的起升三合一專為MRG鋼絲繩電動葫蘆研發的，減速機齒輪硬度研磨和齒面硬化，噪音低、持久耐用。起升電機接電 60%,既滿足了過程中的,又可提高產品的可靠性。進口制動盤，0^100萬次的制動壽命。
Components with high quality are the basis for excellent quality of products. M&R company takes each components seriously from lifting motors to reducers , from reels to steel wire ropes, from safe and reliable electrical components to the best structure components. Because M&R company believes the only each components of good performance and quality can ensure the performance and quality of the complete machine. Lifting trinity mechanism with compact structure and superior performance is developed and designed for MRG series European Electric Wire Rope Hoist. The reduction gear products low noise and becomes durable in use by high precision grinding and hardening treatment of the gear surface.
Electrical connection sustained rate is up to 60% of the lifting motor, which not only meets frequent use during the process of
production, but improves the reliability of the products. The imported brake disc provides the breaking lifetime of more than one million times with excellent wear-resisting property.

Precise positioning and efficient running can improve production efficiency
精準定位，運行高效，提升生產效率
邁德銳標配起升雙速（變頻可選）、小車運行變頻，確保的起重機的平穩運行 車間物流效率的提升，確?？蛻舻母黜?xiàng)工作計劃如期執行。通過變頻技術的的應 用，可以有效減少載荷搬運過程中的晃動，使載荷定更加快速、精準，同時，變頻 技術明顯降低了啟制動時的沖擊,廄個搬運過程更加平穩、安全，
M&R Standard lifting with double speed (optional frequency conversion) and frequency conversion control of trolley ensure the efficient running of the crane and promotion of logistics efficiency in workshop, and ensure the implementation of the whole work plans of customers on schedule. By the application of frequency conversion technology, it can effectively reduce shaking of load in the process of handling, which makes the load positioning more quickly and accurately. Simultaneously, it significantly reduces theimpact of starting and braking , thus the whole handling process becomes much more smooth and safe.
Safe and reliable, running monitoring and simple and convenient maintenance
可靠運行  維修簡單
M&R Patented technology product is provided with various functions such as monitoring, protection, which can ensure safe and reliable operation of the crane, and its running monitoring unit can make detailed records of running condition of electric hoist, running status of motor and safety working cycle, and provide warning in advance. All records can provide data for maintenance, and the root of the problem should be understood to be able to provide maintenance much more timely and efficiently .
