Product Advantage

1. The track is planar and the contact with wheel is optimized from point contact to line contact. The force is more uniform and the swing of lifting object is less < br />.
2. Horizontal steering wheel guide, running more smoothly, less wear on track < br />.
3. Varieties and specifications, wide range of lifting and running speed < br />.
4. Compact structure, small limit size

5. CD, MD series products, parts versatility, after-sales service more convenient < br />.
< br />
Technical parameters

Hulu Model
CD/MD Wide Rail Hoist
Lifting weight (ton)
Zero point five
One
Two
Three
Five
Ten
Maximum elevation (m)
18 m
30 m
30 m
30 m
30 m
30 m
Working Level
M4
Wire rope ratio
2/1
2/1
4/2
Lifting speed of single-speed hoist (m/min)
Eight
Eight
Seven
Lifting speed of double-speed hoist (m/min)
8/0.8
8/0.8
7/0.7
Single-speed hoist motor (kW)
Zero point eight
One point five
Three
Four point five
Seven point five
Thirteen
Double-speed hoist motor (kW)
0.8/0.2
1.5/0.2
3.0/0.4
4.5/0.4
7.5/0.8
13.0/1.5
Operating motor (kW)
Zero point two zero
Zero point two zero
Zero Point Four Zero
Zero Point Four Zero
Zero point five zero
2 & times; 0.5
Fixed type gourd (A)
& radic;
& radic;
& radic;
& radic;
& radic;
& radic;
Monorail trolley hoist (D)
& radic;
& radic;
& radic;
& radic;
& radic;
& radic;
Scope of application






Operating track of non-standard track width such as European main girder or section steel < br/>
